Scott Voltage 910 Electric Mountain Bike 2026
Color
Size
Model
Click & Collect
Scott Voltage 910 Electric Mountain Bike 2026
Carbon Black / S / EU
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609Take your trail rides and shuttle laps to an 11 with the boosted power and range of the long-travel Voltage 910 e-MTB—or better yet, be your own shuttle. Voltage 910’s new secret weapon is TQ’s updated HPR60 motor unit, which pumps out 60Nm of heart-pumped torque for a 20% performance boost over the previous Voltage. No switchback is too tight, and no obstacle is too challenging when you open up this trail monster on the ride.
But it’s not only power that’s improved. Range is also upgraded from the previous Voltage to give you extra “legs” when you want to reach that next peak or send a final lap before sunset. Each Voltage 910 now comes with a Range Extender Battery. It attaches with a quick-release mount and supplies 160 additional watt hours to the 360Wh main battery. It’s the assist you need to enjoy bigger days on the trails, and it’s small enough to pack if you want to have it along on any given ride.
Our NUDE Suspension technology with the Float-X NUDE shock from FOX paired with a fork that favors more adjustability. When you pedal up to have the most fun on the way down, you want a shock that gives you full factory performance when things point downwards, but also a shock that won’t slow you down when you need to ride back up. This is where the Float-X NUDE shines.
This Voltage also comes with SRAM’s Transmission groupset and powerful Maven four-piston brakes to give you the range and the stopping power to make every ride one to remember.
Please note that bike specifications are subject to change without prior notice.
| Frame | Carbon HMFIntegrated Suspension TechnologyVirtual 4 Link kinematic, Adjustable head angleSyncros Cable Integration SystemTQ HPR60, UDH Interface, 12x148mm with 55mm Chainline |
|---|---|
| Fork | FOX 36 Rhythm Air Grip, Sweep Adj., 15x110mm QR axle, tapered steerer44mm offset, Reb. Adj., Lockout, 160mm travel |
| Rear Shock | FOX FLOAT X NUDE EVOL Piggy Back Trunnion, SCOTT custom w. travel, geo adj.3 modes: Climb-Ramp Control-DescendCustom large Air volume, Comp & Reb. Adj. Travel 155-100-Climb, T185X55mm |
| Remote System |
TracLoc TechnologyRear Suspension & Dropper Remote3 Rear Suspension modes
|
| Headset | Syncros - Acros Angle adjust & Cable Routing HS SystemStainless, +-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB |
| Stem | Syncros AM 1.54° rise, 7050 Alloy, 31.8mm, 1 1/8"Syncros Cable Integration System |
| Handlebars | back sweep 8°, 780mmSyncros Hixon 1.5 Alloy 7050, Size S & M 15mm rise, Size L & XL 25mm riseSyncros Endurance lock-on grips |
| Rims | Syncros X-30S, 32H, 30mm, Sleeve JointTubeless ready |
| Front Hub | Formula CL-811, 15x110mm |
| Rear Hub | Formula CL-148S, 12x148mm |
| Spokes | Stainless Black 15G, 1.8mm |
| Front Tyre | Maxxis Assegai, 2.5", 60TPI FoldableTubeless Ready, EXO+ 3C Maxx Terra |
| Rear Tyre | Maxxis Dissector, 2.5", 60TPI FoldableTubeless Ready, EXO+ 3C Maxx Terra |
| Shifter | SRAM AXS Rocker Pod Controller |
| Rear Derailleur | SRAM S1000 Eagle AXS Transmission 12 SpeedWireless Electronic Shift System |
| Crankset | Praxis Alloy Praxis alloy spider, SRAM Eagle Transmission 34T chainring |
| Cassette | SRAM Eagle XS 1270 Transmission 10-52 |
| Chain | SRAM CN GX Eagle Transmission |
| Chainguide | e*thirteen, e*spec Slider |
| Brakes | SRAM Maven Bronze Stealth 4-Piston Disc |
| Rotors | SRAM HS2 Rotors F&R 200mm |
| Seatpost | Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mmS size 140mm, M size 180mm, L size 180mm, XL size 210mm |
| Saddle | Syncros Tofino 1.5 RegularTitanium rails |
| Extras | SRAM AXS Extension Cord |
| Weight | 19.9 Tubless setup without RE (1.1kg) |
| Motor | TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh |
| Battery | TQ Internal 360Wh + TQ Range Extender 160Wh |
| Display | TQ HPRBluetooth, ANT+, Dedicated Smartphone app |
| Charger | TQ 100-240V-4A |
Geometry

| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 622.3 | 622.4 | 631.3 | 640.2 |
| Reach | 437.4 | 457.2 | 485 | 512.7 |
| Headtube Angle | 63.9 | 63.9 | 63.9 | 63.9 |
| Headtube Length | 110 | 110 | 120 | 130 |
| Seattube Angle | 77.1 | 77.1 | 77.1 | 77.1 |
| Seattube Length | 404.6 | 424.5 | 449.6 | 479.7 |
| Toptube (Effective) | 580.2 | 600 | 629.9 | 659.8 |
| Chainstay Length | 455 | 455 | 455 | 455 |
| Wheelbase | 1232.8 | 1252.6 | 1284.8 | 1316.9 |
| BB Height | 349.6 | 349.5 | 349.6 | 349.7 |
| BB Drop | 27.4 | 27.5 | 27.4 | 27.3 |
| Standover | 765 | 765 | 772 | 788 |
| Fork Length | 571 | 571 | 571 | 571 |
| Trail | 135.7 | 135.7 | 135.7 | 135.7 |
| Stem Length | 40 | 40 | 50 | 50 |
| Crank Length | 170 | 170 | 175 | 175 |
| Max Seatpost Insertion | 190 | 210 | 235 | 265 |
