Scott Sub Tour 10 Electric Hybrid Bike 2026
Color
Size
Click & Collect
Scott Sub Tour 10 Electric Hybrid Bike 2026
Kelp Green / S
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609Empower your rides around town with the smooth rolling and versatile Sub Tour 10 E-Bike. For commutings into the office, a full day of running errands with the wind in your hair, or exploring beyond the city on a chill weekend with the fam, the Sub Tour delivers the power to easily handle it all.
Driven by Bosch’s quiet Performance PX motor and 800Wh battery, Sub Tour's intuitive handling makes it feel natural to ride. Accelerations are smooth, getting over the hills is a breeze, and there’s a power mode for any situation you’ll need Sub Tour to tackle. Its rear rack can support up to 27kg—including an optional kids’ seat. Think of it as your escape from the traffic that lets you embrace movement and enjoy the ride.
This Sub Tour uses a hidden gear cluster in the rear hub, which extends the lifespan of the drivetrain and means less maintenance for you as well. And out front, a suspension fork makes rough roads on your route a piece of cake.
Please note that bike specifications are subject to change without prior notice.
Specifications
| Frame | Alloy S-XL=29", 6061 Alloy custom butted tubingSide extraction batteryUDH Interface, 135mm with 46mm Beltline |
|---|---|
| Fork | SR Suntour XCM34 LO Coil, Tapered, 15x110 TA, Lock Out, 100mm Travel |
| Headset | Acros, 1.5"- 1.5"semi integ. OD 50/61mm, ID 44/55mm |
| Stem | Syncros UC 3.0 adjustable with front Light mount and Intuvia 100 mount |
| Handlebars | Syncros UC3.0 680mm, Rise 12mm, Backsweep 15° |
| Rims | Syncros X18 Disc |
| Spokes | Black Spokes |
| Front Hub | Shimano HBTC50015BB CL, 15x110mm |
| Rear Hub | Shimano Nexus Inter 5e |
| Front Tyre | Schwalbe Big Apple Performance, 60-622 |
| Rear Tyre | Schwalbe Big Apple Performance, 60-622 |
| Shifter | Shimano Nexus Inter 5e |
| Crankset | FSA CK-220 170mm |
| Chainring | Gates CDX 46T w/Guard |
| Cassette | Gates CDX 32T |
| Chain | Gates CDX 130T |
| Brakes | Shimano BR-MT200 Disc |
| Rotors | Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 160mm |
| Seatpost | Syncros 3.0, 31.6mm, 350mm |
| Saddle | Syncros Capilano |
| Pedals | Marwi SP-828 |
| Mudguards | Curana alloy profile Fender |
| Rear Rack | Racktime carrier SnapIt 2.0 27KG |
| Lights | Front Lezyne Hecto E65 Rear Lezyne Light |
| Kickstand | Ursus Kickstand |
| Weight | 28.1kg |
| Motor | Bosch Performance Line PX (BDU347Y)EU: 25kmh |
| Battery | PowerTube 800Wh |
| Display | Bosch System ControllerKiox 300, Mini remote |
| Charger | 2A Charger |
Geometry
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Stack | 636 | 636 | 641 | 651 | 660 |
| Reach | 425.4 | 425.4 | 444.2 | 461.8 | 479.4 |
| Headtube Angle | 67.2 | 67.2 | 68.2 | 68.2 | 68.2 |
| Headtube Length | 130 | 130 | 130 | 140 | 150 |
| Seattube Angle | 77 | 77 | 77 | 77 | 77 |
| Seattube Length | 370 | 400 | 440 | 490 | 540 |
| Toptube (Effective) | 577 | 577 | 597 | 617 | 637 |
| Chainstay Length | 482 | 482 | 482 | 482 | 482 |
| Wheelbase | 1205.7 | 1197.1 | 1205.7 | 1227.2 | 1248.8 |
| BB Height | 302.4 | 302.4 | 302.4 | 302.4 | 302.4 |
| BB Drop | 72.6 | 72.6 | 72.6 | 72.6 | 72.6 |
| Standover | 752.2 | 767.2 | 768 | 805.4 | 840.1 |
| Trail | 115.6 | 115.6 | 108.3 | 108.3 | 108.3 |
| Stem Length | 90 | 90 | 90 | 90 | 90 |
