Scott Sub Sport 20 Wave Electric Hybrid Bike 2026
Color
Size
Click & Collect
Scott Sub Sport 20 Wave Electric Hybrid Bike 2026
Hematite Blue / S
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609The Sub Sport 20 Wave E-Bike is the smart and convenient way to embrace cycling in the city and a great value. With its step-through frame design that favors most riders and its strong, user-friendly Bosch motor, it’s a bike that makes urban riding a breeze and delivers range for every journey.
Its frame shape eliminates the need to throw a leg over the saddle, and makes it an approachable design that’s comfortable to mount and dismount, and versatile with any type of clothing you’ll be pedaling to your destination.
The Sub Sport 20 Wave uses the quiet Bosch’s Performance PX motor and an 600Wh battery unit. When you start pedaling, the power delivery feels smooth and natural, inspiring confidence for rides in busier areas of town and navigating inclines. There are also multiple mode settings to select to dial in the perfect amount of juice you need for any ride you’ll do on Sub Sport.
Its balanced geometry, stable platform, and front suspension provide exceptional handling, ensuring a comfortable ride even on rough pavement.
Whether you’re commuting to work, running errands, or embarking on longer routes, the Sub Sport 20 Wave excels, and can carry up to 25kg on its rear rack (fitting an optional kids’ seat for the little ones). Combined with Shimano’s 10-speed drivetrain, it offers the perfect gearing and power to make urban riding the most efficient and enjoyable way to get around.
Please note that bike specifications are subject to change without prior notice.
Specifications
| Frame | Alloy S-XL=29", 6061 Alloy custom butted tubingTop extraction batteryUDH Interface, 12x148mm with 52mm Chainline |
|---|---|
| Fork | SR Suntour XCM34 LO Coil, Tapered, 15x110 bolt Axle, Lock Out, 100mm Travel |
| Headset | Acros, 1.5"- 1.5"semi integ. OD 50/61mm, ID 44/55mm |
| Stem | Syncros UC 3.0 adjustable with front Light mount |
| Handlebars | Syncros UC3.0 680mm, Rise 12mm, Backsweep 15° |
| Rims | Syncros X18 Disc |
| Spokes | Black Spokes |
| Front Hub | Shimano HBTC50015BB CL, 15x110mm |
| Rear Hub | Shimano FHTC500HMBB, 148x12mm |
| Front Tyre | Schwalbe Big Apple Performance, 60-622 |
| Rear Tyre | Schwalbe Big Apple Performance, 60-622 |
| Shifter | Shimano CUES RD-U6000GS 10 Speed |
| Rear Derailleur | |
| Crankset | FSA CK-220 170mm |
| Chainring | FSA 38T |
| Cassette | Shimano CS-LG40010 11-48 T |
| Chain | Shimano LG500 |
| Brakes | Shimano BR-MT200 Disc |
| Rotors | Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 160mm |
| Seatpost | Syncros 3.0, 31.6mm, 350mm |
| Saddle | Syncros Capilano |
| Pedals | Marwi SP-828 |
| Mudguards | |
| Rear Rack | Racktime carrier SnapIt 2.0 25KG |
| Lights | Front Lezyne Hecto E65Rear Lezyne Light |
| Kickstand | |
| Weight | 29.8kg |
| Motor | Bosch Performance Line PX (BDU347Y)EU: 25kmh |
| Battery | PowerTube 600Wh |
| Display | Bosch Purion 200 |
| Charger | 2A Charger |
Geometry

| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 696 | 688 | 705 | 705 |
| Reach | 413 | 433 | 450 | 450 |
| Headtube Angle | 68.2 | 68.2 | 68.2 | 68.2 |
| Headtube Length | 160 | 160 | 170 | 170 |
| Seattube Angle | 76.9 | 76.9 | 76.9 | 76.9 |
| Seattube Length | 440 | 480 | 520 | 560 |
| Toptube (Effective) | 575 | 595 | 615 | 615 |
| Chainstay Length | 482 | 482 | 482 | 482 |
| Wheelbase | 1190 | 1210 | 1232 | 1232 |
| BB Height | 299.5 | 299.5 | 299.5 | 299.5 |
| BB Drop | -75.5 | -75.5 | -75.5 | -75.5 |
| Standover | 638 | 633 | 630 | 630 |
| Trail | 100 | 100 | 100 | 100 |
| Stem Length | 90 | 90 | 90 | 90 |
