Scott Solace Gravel 20 Electric Gravel Bike 2026
Color
Size
Model
Click & Collect
Scott Solace Gravel 20 Electric Gravel Bike 2026
Squid Blue/Beluga Grey / XL / EU
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609The Solace Gravel 20 E-Bike is an all-rounder that can handle anything you throw at it. Its confidence-inspiring geometry and endurance-focused riding position make it a great choice for exploring every gravel frontier. With its lightweight carbon frame, generous tire clearance, and updated TQ HPR60 motor unit, the e-bike is stronger, more confident, and more efficient than ever.
Power is boosted compared to its predecessor, now with 60Nm of torque that allows you to conquer even the steepest inclines with ease and stamina. It’s the grunt you’ll need to monster over mountains and the support your legs will ask for after a long day in the saddle.
We built this Solace with SRAM’s Rival XLPR AXS groupset and Syncros Capital 1.0 40e wheels on 50mm Schwalbe G-One Overland tires, making it a setup that’s built for gravel excellence without the top-tier price tag.
Please note that bike specifications are subject to change without prior notice.
Specifications
| Frame | Solace Gravel Disc HMX, Endurance geometry, Syncros Cable Integration System, TQ HPR60, UDH Interface, Range Extender Included |
|---|---|
| Fork |
1 1/4"-1 1/2" Eccentric Carbon steererSolace Gravel HMF Flatmount Disc |
| Headset | Acros AIF-1135 |
| Handlebars | Syncros Creston 1.0 XCarbon 31.8mm |
| Wheels | Syncros Capital 1.0 40e Disc24 Front 12x100mmTA /24 Rear 12x142mm TA Syncros Axle w/Removable Lever with Tool |
| Front Tyre | Schwalbe G-One Overland EVO, 700x50C |
| Rear Tyre | Schwalbe G-One Overland EVO, 700x50C |
| Shifter | SRAM RIVAL AXS HRD Shift-Brake System |
| Rear Derailleur | SRAM RIVAL XPLR eTap AXS, 13 Speed |
| Crankset | Praxis TQ Alloy |
| Chainring | SRAM X-SYNC42T 107 BCD |
| Cassette | SRAM XPLR XG1351, 10-46 |
| Chain | SRAM RIVAL |
| Brakes | SRAM RIVAL eTap AXS HRD Shift-Brake System, Flatmount |
| Rotors | SRAM HS2 rotor 160/F and 160/R |
| Seatpost | Syncros Duncan 1.0 iL D-shape |
| Saddle | Syncros Tofino Regular 2.0 Cutout |
| Lights | Syncros Campbell iL rear |
| Weight | 13.8kg |
| Motor | TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh |
| Battery | TQ Internal 360Wh |
| Display | TQ HPR 60, Bluetooth, ANT+, AXS, Dedicated Smartphone app |
| Charger | TQ AC 90-264V 4A |
Geometry
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Stack | 519.3 | 544.7 | 565.6 | 590.2 | 610 |
| Reach | 374 | 378 | 387 | 398 | 406 |
| Headtube Angle | 69.5 | 70 | 71 | 71 | 71 |
| Headtube Length | 85 | 110 | 128 | 154 | 175 |
| Seattube Angle | 74.5 | 74 | 73.5 | 73 | 73 |
| Seattube Length | 477 | 507 | 527 | 547 | 567 |
| Toptube (Effective) | 518 | 534.2 | 554.5 | 578.4 | 592.5 |
| Chainstay Length | 435 | 435 | 435 | 435 | 435 |
| Wheelbase | 1021.5 | 1030.1 | 1036.8 | 1056.2 | 1071.1 |
| BB Height | 294 | 294 | 294 | 294 | 294 |
| BB Drop | 76 | 76 | 76 | 76 | 76 |
| Standover | 759 | 785 | 803 | 824 | 841 |
| Trail | 80.8 | 77.5 | 70.7 | 70.7 | 70.7 |
| Stem Length | 80 | 90 | 100 | 100 | 110 |
