Scott Scale Gravel RC Gravel Bike 2026
Color:
Color
Size:
Size
Quantity:
Click & Collect
Pickup currently unavailable at Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Scott Scale Gravel RC Gravel Bike 2026
Carbon Black / S
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Pickup currently unavailable
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Pickup available, usually ready in 5+ days
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609The Scale Gravel RC was put on this planet for going on adventures with attitude. Designed to go the distance over any and all types of terrain, and to do so in a hurry, the Scale Gravel RC is lightweight with agile handling and features multiple mounting options. No matter what sits between you and the finish line, know you'll always get there in no time.
Please note that bike specifications are subject to change without prior notice.
Specifications
| Frame | Scale Carbon HMF Adjustable head angle, Syncros Cable Integration System Advanced Shock & Standing Damping System BB92, UDH Interface, 12x148mm with 55mm Chainline |
|---|---|
| Fork | Scale Rigid HMFPostmount Disc StandardTapered Carbon steerer |
| Headset | Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB |
| Handlebars | Syncros Fraser iC SL XC Carbon-20° rise, back sweep 8°, 740mmSyncros Performance XC lock-on grips |
| Wheels | Syncros Silverton 1.0X CLF: 15x110mm, R: 12x148mmTubeless ready Carbon rim 28H, XD DriverSyncros Axle w/Removable Leverwith 6mm Allen, T30 and T25 Tools |
| Tyres | Schwalbe Thunder Burt 29x2.35" EVOSuper Ground, TLE, 67EPI, Addix Speed |
| Shifter | SRAM AXS Rocker Pod Controller |
| Rear Derailleur | SRAM X0 Eagle AXS Transmission 12 SpeedWireless Electronic Shift System |
| Crankset | SRAM X0 Eagle TransmissionSpindle Power Meter, DUB, 55mm CL, 34T |
| Cassette | SRAM X0 Eagle XS 1295 Transmission 10-52 |
| Chain | SRAM CN X0 Eagle Transmission |
| Bottom Bracket | SRAM DUB PF 92 MTB Wide, shell 41x92mm |
| Brakes | SRAM Motive Silver 4-Piston Disc |
| Rotors | SRAM HS2 CL Rotors 180/F and 160/R |
| Seatpost | Syncros Duncan 1.0 Carbon, 10mm offset31.6x400mm |
| Saddle | Syncros Belcarra V2.0 Cut OutCRMO rails |
| Extras | SRAM AXS Powerpack, Spirgrips+ Inner Bar ends, Milkit Tire Sealant |
| Weight | 9.1 |
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 600.3 | 604.9 | 618.9 | 628.1 |
| Reach | 418.5 | 442.3 | 463.6 | 491.2 |
| Headtube Angle | 67.9 | 67.9 | 67.9 | 67.9 |
| Headtube Length | 90 | 95 | 110 | 120 |
| Seattube Angle | 75.4 | 75.4 | 75.3 | 75.3 |
| Seattube Length | 390 | 440 | 480 | 530 |
| Toptube (Effective) | 575 | 600.2 | 626 | 656.5 |
| Chainstay Length | 425 | 425 | 425 | 425 |
| Wheelbase | 1105.4 | 1131.1 | 1158 | 1189.4 |
| BB Drop | -62 | -62 | -62 | -62 |
| BB Height | 313 | 313 | 313 | 313 |
| Standover | 752 | 781 | 800 | 835.1 |
| Fork Length | 506 | 506 | 506 | 506 |
| Trail | 105 | 105 | 105 | 105 |
| Stem Length | 50 | 60 | 70 | 80 |
| Maximum Seatpost Insertion | 160 | 210 | 250 | 300 |
| Crank Length | 170 | 170 | 175 | 175 |
