Scott Lumen 920 Electric Mountain Bike 2026
Color
Size
Model
Click & Collect
Scott Lumen 920 Electric Mountain Bike 2026
White / S / EU
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609For the thrill of a lightweight eMTB in a build that won’t break the bank, the Lumen 920 is a must-have ride. With a carbon front and alloy rear triangle, it maintains the playful, agile, and responsive handling quality riders love about our full-carbon Lumens. With the new TQ HPR60 motor unit giving more torque than ever, you can wring out your best performances.
Lumen 920’s juice centers around TQ’s lightweight HPR60 motor unit that now supplies 60NM of trail-blasting torque to conquer the steepest climbs and roll over the challenging features. It’s a 20% increase in performance over the previous Lumen and one that doesn’t add any weight either. So, Lumen 920 still feels like a traditional, intuitive, non-powered MTB in the tech instead of bringing the heft of a bigger eMTB to manage.
Lumen 920 has more range than ever, too. Included with every Lumen 920 is a Range Extender Battery that complements the 360Wh main battery. It easily attaches with a quick-release mount or stows away in a pack to carry along—in case you want to get that extra lap in before sunset.
Specifications
| Frame | Carbon HMF Main Frame, Alloy SST-CSTIntegrated Suspension TechnologyFlex Pivot, Adjustable head angleSyncros Cable Integration System, UDH Interface, 12x148mm with 55mm Chainline |
|---|---|
| Fork |
2-Modes / 15x110mm axle / tapered steerer42mm offset / Reb. Adj. / Lockout / 140mm traveRockShox Recon Gold RL Solo Air
|
| Rear Shock | X-Fusion NUDE 5 RLX TrunnionSCOTT custom w. travel, geo adj.3 modes: Lockout-Traction Control-DescendReb. Adj.Travel 130-90-Lockout, T165X45mm |
| Remote System | SCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes |
| Headset | Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB |
| Stem | Syncros DC 2.0Syncros Cable Integration System0° rise, 6061 Alloy, 31.8mm, 1 1/8" |
| Handlebars | Syncros Fraser 2.0 DC Alloy 6061 D.B.mini Rise, back sweep 8°, 760mmSyncros Performance XC lock-on grips |
| Rims | Alexrims X-30S, 32H, 30mmTubeless ready |
| Spokes | Stainless Black 15G, 1.8mm |
| Front Hub | Formula CL-811, 15x110mm |
| Rear Hub | Formula CL-148S, 12x148mm |
| Tyres | Schwalbe Wicked Will 29x2.4" EVOSuper Race, TLE, 67EPI, Addix Speed Soft |
| Shifter | SRAM Eagle 70, TriggerShifter |
| Rear Derailleur | SRAM Eagle 70 Transmission 12 Speed |
| Crankset | Praxis Alloy, Praxis spider, SRAM Eagle Transmission 34T chainring |
| Cassette | SRAM Eagle XS 1270 Transmission 10-52 |
| Chain | SRAM Eagle 70 Transmission |
| Chainguide | e*thirteen, e*spec Slider |
| Brakes | SRAM DB4 Stealth 4-Piston Disc |
| Rotors | SRAM HS2 CL Rotors, F&R 180mm |
| Seatpost | Syncros Duncan Dropper Post 2.031.6mm, S & M size 125mm, L size 150mm, XL size 170mm |
| Saddle | Syncros Tofino 2.0 RegularCRMO rails |
| Weight |
18.5 Tubless setup without RE (1.1kg)
|
| Motor | TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh |
| Battery | TQ Internal 360Wh + Range Extender 160Wh |
| Display | TQ HPRBluetooth, ANT+, Dedicated Smartphone app |
| Charger | TQ 100-240V-4A |
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 615 | 615 | 625 | 638 |
| Reach | 416 | 446 | 476 | 501 |
| Headtube Angle | 65.5 | 65.5 | 65.5 | 65.5 |
| Headtube Length | 110 | 110 | 120 | 135 |
| Seattube Angle | 76.8 | 77 | 77.2 | 77.5 |
| Seattube Length | 415 | 440 | 480 | 520 |
| Toptube (Effective) | 562 | 589 | 620 | 645 |
| Chainstay Length | 450 | 450 | 450 | 450 |
| Wheelbase | 1176 | 1206 | 1240 | 1270 |
| BB Height | 338.5 | 338.5 | 338.5 | 338.5 |
| BB Drop | -38.5 | 38.5 | 38.5 | 38.5 |
| Standover | 765 | 767 | 780 | 800 |
| Fork Length | 540 | 540 | 540 | 540 |
| Stem Length | 580 | 60 | 70 | 70 |
| Maximum Seatpost Insertion | 150 | 175 | 215 | 255 |
| Crank Length | 170 | 170 | 175 | 175 |
