Scott Genius 910 TR Full Suspension Mountain Bike
Carbon Black/Splatters White / M / TW
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Pickup currently unavailable
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Pickup available, usually ready in 5+ days
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609The Genius has always been our favorite bike. Smart suspension, smarter features, and the smartest design lead to an unbelievable trail bike that just can't get enough. The Genius, any trail, any time.
Please note that bike specifications are subject to change without prior notice
Specifications
| frame | Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline |
|---|---|
| fork | FOX 36 Float Performance Elite Air FIT4, 3-Modes with low Speed adj. / Kabolt 15x110mm axle, 44mm offset / tapered steerer / Reb. Adj. / Lockout, 160mm travel |
| rear-shock | FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 150-100-Lockout / T185X55mm |
| derailleur | SRAM GX Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System |
| shift-levers | SRAM GX Eagle AXS Rocker Controller |
| front-derailleur | |
| brake-front | Shimano XT M8120 4 Piston Disc |
| brake-rear | Shimano XT M8120 4 Piston Disc |
| brake-disc-front | Shimano SM-RT76 / 6 Bolt / 203mm |
| brake-disc-rear | Shimano SM-RT76 / 6 Bolt / 180mm |
| wheelset | Syncros Revelstoke 1.5 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools |
| rims | |
| tire-front | Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra |
| tire-rear | Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxxTerra |
| hub-front | |
| hub-rear | |
| spokes | |
| handlebar | Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm |
| stem | |
| headset | Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| grips | Syncros Endurance lock-on grips |
| saddle | Syncros Tofino 1.5 Regular, Titanium rails |
| seat-post | Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm, L size 170mm / XL size 200mm |
| crankset | SRAM GX Eagle Transmission, DUB / 55mm CL / 32T |
| bottom-bracket | SRAM DUB PF 92 MTB Wide / shell 41x92mm |
| Chain | SRAM CN GX Eagle Transmission |
| Cassette | SRAM GX Eagle XS 1275 Transmission 10-52 |
| Pedals | |
| motor | |
| battery | |
| display | |
| charger |
Specifications
| stack | 617 |
|---|---|
| reach | 430 |
| seat-tube-length | 380 |
| seat-tube-angle | 76,8 |
| top-tube-length | 570 |
| head-tube-length | 90 |
| head-tube-angle | |
| stem-length | 40 |
| handlebar-width | 780 |
| wheelbase | 1182 |
| standover | 729 |
| chainstay-length | 440 |
| fork-rake | 44 |
| bottom-bracket-height | 343 |
| bottom-bracket-drop | 33 |
