Scott Contessa Patron eRIDE 900 Electric Mountain Bike
Color
Size
Model
Click & Collect
Scott Contessa Patron eRIDE 900 Electric Mountain Bike
Prism Unicorn Purple / S / NL
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,
Johnstown Rd,
Dún Laoghaire,
Co. Dublin
Warehouse
Unit 9, Hills Hire Centre,
Johnstown Rd,
Dún Laoghaire,
Co. Dublin
The Contessa Patron eRIDE 900 was designed as a system optimized for all day trail riding. Supreme integration, women specific components and meticulously selected geometry paired with a powerful new Bosch motor deliver much more than a great ride. What you get, rather, is a sublime experience up and down the mountain, time and time again. Patron eRIDE - boss the trails.
Please note that bike specifications are subject to change without prior notice
Specifications
"| frame | Carbon Main Frame / Alloy SST-CST-Link, Virtual 4 link kinematic VLK, 29x2.6 / Boost 148x12mm UDH, 160mm travel / Bosch SmartSystem / Integr. removable Battery, 1.8" Headtube, Central Kickstand Mount, Integr. Cable |
|---|---|
| fork | FOX 38 Perf. Elite Air / eMTB+ / FIT4, 3 modes with low Speed adj. / QR Axle 15x110mm axle, 44mm offset / tapered steerer / Reb. Adj. / Lockout / 160mm travel |
| rear-shock | FOX NUDE T eRIDE EVOL / Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, custom large air volume / DPS / Reb. Adj., Travel 160-115-Lockout / 205X60mm |
| derailleur | Shimano XT / 12 Speed |
| shift-levers | Shimano SL-M8100 |
| front-derailleur | |
| brake-front | Shimano XT / BR-M8120 4 Piston |
| brake-rear | Shimano XT / BR-M8120 4 Piston |
| brake-disc-front | RT-MT800 CL 203mm |
| brake-disc-rear | RT-EM800 CL 203mm |
| wheelset | |
| rims | Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready |
| tire-front | Maxxis Dissector 29x2.6", 120TPI Foldable Bead, EXO+ / TR Tubeless ready, 3C Maxx Terra |
| tire-rear | Maxxis Dissector 29x2.6", 120TPI Foldable Bead, EXO+ / TR Tubeless ready, 3C Maxx Terra |
| hub-front | Formula CL-811 / 15x110mm |
| hub-rear | Formula ECT-1481 / Boost 148x12mm |
| spokes | Stainless Black |
| handlebar | Syncros Hixon 1.5 / Alloy 7050D.B., 12mm rise / 9° / 780mm |
| stem | Syncros AM1.5 / 7050 Alloy, 31.8mm / 4° / 1 1/8" |
| headset | Acros / 1.8", ZS66 OD74 / integr. Cable |
| grips | Syncros Endurance lock-on grips |
| saddle | Syncros Savona 1.5, CRMO rails |
| seat-post | FOX Transfer Dropper Post, 31.6mm / S size 125mm / M size 150mm / L size 175mm |
| crankset | FSA CK-745 165mm / 34T |
| bottom-bracket | |
| Chain | Shimano CN-M8100 |
| Cassette | Shimano CS-M8100 / 10-51T |
| Pedals | |
| motor | Bosch Performance CX, EU: 25kmh / INT: 20mph |
| battery | PowerTube 750Wh |
| display | Bosch LED Remote & Kiox 300 |
| charger | 4A Charger |
Specifications
| stack | 635 |
|---|---|
| reach | 433 |
| seat-tube-length | 411 |
| seat-tube-angle | 77 |
| top-tube-length | 579 |
| head-tube-length | 120 |
| head-tube-angle | 64,5 |
| stem-length | 40 |
| handlebar-width | 780 |
| wheelbase | 1222 |
| standover | 766 |
| chainstay-length | 454 |
| fork-rake | 42 |
| bottom-bracket-height | 347 |
| bottom-bracket-drop | 30 |
