Scott Addict Gravel RC HMX Frameset
Availability
Click & Collect
Scott Addict Gravel RC HMX Frameset
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609The Scott Addict Gravel RC will get you wherever you’re going, no matter what the trail throws at you. More progressive, more control and more mounts mean this adventure-ready machine is your ticket to getting out there. Find yourself, get lost.
Specifications
Frame:
HMX Carbon Disc Mainframe with UDH hangercompatible for eletr. and mech. Shifting
Fork:
HMX Carbon fork for Disc Brake
Accessories:
ACROS AIF-1135 HeadsetExpander for Carbon Steertube and TopcapSyncros SP-R101-CF seatpostSyncros SL ROAD plug-in thru axle
Approx Weight:
Frame 930g / Fork 395g
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Stack | 519 | 544.4 | 565.3 | 589.9 | 609.7 |
| Reach | 374.1 | 378.4 | 387.1 | 398.2 | 406.1 |
| Headtube Angle | 70 | 70 | 71 | 71 | 71 |
| Headtube Length | 95 | 122 | 140 | 166 | 187 |
| Seattube Angle | 74.5 | 74 | 73.5 | 73 | 73 |
| Seattube Length | 477 | 507 | 528 | 546 | 566 |
| Toptube (Effective) | 518 | 534.5 | 554.5 | 578.5 | 592.5 |
| Chainstay Length | 425 | 425 | 425 | 425 | 425 |
| Wheelbase | 1009.4 | 1022.9 | 1029.2 | 1048.7 | 1063.5 |
| BB Height | 283 | 283 | 283 | 283 | 283 |
| BB Drop | 71 | 71 | 71 | 71 | 71 |
| Standover | 759 | 786 | 807 | 828 | 847 |
| Stem Length | 83 | 93 | 103 | 103 | 113 |
