Polygon Syncline C5 Hardtail MTB
Color:
Color
Size:
Size
Quantity:
Click & Collect
Pickup currently unavailable at Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Polygon Syncline C5 Hardtail MTB
Red/Black / S - 27.5"
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Pickup currently unavailable
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Pickup available, usually ready in 5+ days
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609SEIZE THE JOURNEY
An adrenaline machine to ride on more trails
Designed as a top performing XC trail machine with modern geometry. Featuring an ultra light and stiff carbon frame designed around 27.5” and 29″ wheels, this bike will keep you rolling on cross country to technical tracks smoothly with style. This is for you, trail seeker. Whether you are looking for fun off-road riding or cross-country enthusiast striving for podiums, get ready to cross every boundary and seize your own journey.
Comes with a slack head tube angle and short chainstay, Syncline C takes you to have an excellent acceleration and the best performance on switchback turns. Along with the reliable hydraulic disc brakes, you are in control.
There’s more in less. The biggest advantage from a 1x drivetrain is it lets you to focus on your ride, instead of constantly adjusting gears. Now you can have more and better experience on trails.
Built with adaptive carbon frame, Synline C gives you a better pedaling efficiency and riding feel. The journey is yours.
Less flex for excellent front-end control with its tapered head tube design
Specifications
| Syncline C5 | Syncline C3 | |
|---|---|---|
| Frame | ACX XC PERFORMANCE | |
| Fork | FOX 32 RHYTHM, 120mm | |
| Headset | INTEGRATED W/ SEALED BEARING FOR TAPER HEAD TUBE, IS 42/28.6 | IS 52/40 | |
| Stem | ENTITY XPERT, EXT: 60mm, BB: 31.8mm, R/D: 7degree | |
| Handlebars | ENTITY XPERT, W: 740mm, BB: 31.8mm, R/D: 12mm, B: 9degree | |
| Wheels | ALLOY DOUBLE WALL | |
| Rims |
Rim
|
|
| Tyres | WTB TRAIL BOSS TIRE, 27.5x2.25 / 29x2.25 | |
| Shifter | SHIMANO SLX SL-M7100-R 12-SPEED TRIGGER | |
| Rear Derailleur | SHIMANO SLX RD-M7100-SGS DIRECT ATTACH | |
| Crankset | SHIMANO SLX FC-M7100-1 32T 2-PIECE-CRANK | |
| Cassette | 12 SPEED 11-51T | |
| Chain | KMC NEW X-12 | |
| Bottom Bracket | SHIMANO BB-MT500-PA | |
| Brakes | SHIMANO MT400 HYDRAULIC DISC BRAKE | |
| Brake Levers | SHIMANO MT400 HYDRAULIC DISC BRAKE | |
| Rotors | FRONT:180mm REAR:160mm CENTER-LOCK | |
| Seatpost | ENTITY XPERT, 27.2x350mm | |
| Saddle | ENTITY VOID SADDLE |
Geometry
| S - 27.5" | M - 27.5" | M - 29" | L - 29" | XL - 29" | |
|---|---|---|---|---|---|
| Stack | 596.6 | 615 | 633.2 | 651.6 | 670 |
| Reach | 410 | 430 | 430 | 450 | 470 |
| Headtube Angle | 67 | 67 | 67 | 67 | 67 |
| Headtube Length | 100 | 120 | 100 | 120 | 140 |
| Seattube Angle | 73 | 73 | 73 | 73 | 73 |
| Seattube Length | 380 | 420 | 420 | 460 | 500 |
| Toptube (Effective) | 569 | 594.6 | 597.7 | 621 | 649.15 |
| Chainstay Length | 428 | 425 | 435 | 435 | 435 |
| Wheelbase | 1060.94 | 1134.8 | 1149.5 | 1176.9 | 1204.76 |
| BB Height | 308 | 308.5 | 307.5 | 307.5 | 304.5 |
| BB Drop | 45 | 45 | 65 | 65 | 65 |
| Standover | 690.9 | 729.2 | 730.8 | 763.7 | 779.2 |
