SEIZE THE JOURNEY
An adrenaline machine to ride on more trails
Designed as a top performing XC trail machine with modern geometry. Featuring an ultra light and stiff carbon frame designed around 27.5” and 29″ wheels, this bike will keep you rolling on cross country to technical tracks smoothly with style. This is for you, trail seeker. Whether you are looking for fun off-road riding or cross-country enthusiast striving for podiums, get ready to cross every boundary and seize your own journey.
Comes with a slack head tube angle and short chainstay, Syncline C takes you to have an excellent acceleration and the best performance on switchback turns. Along with the reliable hydraulic disc brakes, you are in control.
There’s more in less. The biggest advantage from a 1x drivetrain is it lets you to focus on your ride, instead of constantly adjusting gears. Now you can have more and better experience on trails.
Built with adaptive carbon frame, Synline C gives you a better pedaling efficiency and riding feel. The journey is yours.
Less flex for excellent front-end control with its tapered head tube design
Specifications
| Syncline C5 | Syncline C3 | |
|---|---|---|
| Frame | ACX XC PERFORMANCE | ACX XC PERFORMANC |
| Fork | FOX 32 RHYTHM, 120mm | ROCKSHOX RECON SILVER RL, 120mm |
| Headset | INTEGRATED W/ SEALED BEARING FOR TAPER HEAD TUBE, IS 42/28.6 | IS 52/40 | INTEGRATED W/ SEALED BEARING FOR TAPER HEAD TUBE, IS 42/28.6 | IS 52/40 |
| Stem | ENTITY XPERT, EXT: 60mm, BB: 31.8mm, R/D: 7degree | ENTITY XPERT, EXT: 60mm, BB: 31.8mm, R/D: 7degree |
| Handlebars | ENTITY XPERT, W: 740mm, BB: 31.8mm, R/D: 12mm, B: 9degree | ENTITY XPERT, W: 740mm, BB: 31.8mm, R/D: 12mm, B: 9degree |
| Wheels | ALLOY DOUBLE WALL | ALLOY DOUBLE WALL |
| Rims |
Rim
|
584-30 / 622-30 32H FOR TYRE 584 / 622-54/76 TUBELESS READY |
| Tyres | WTB TRAIL BOSS TIRE, 27.5x2.25 / 29x2.25 | WTB TRAIL BOSS TIRE, 27.5x2.25 / 29x2.25 |
| Shifter | SHIMANO SLX SL-M7100-R 12-SPEED TRIGGER | SHIMANO DEORE SL-M6100-R 12-SPEED TRIGGER |
| Rear Derailleur | SHIMANO SLX RD-M7100-SGS DIRECT ATTACH | SHIMANO DEORE RD-M6100-SGS DIRECT ATTACH |
| Crankset | SHIMANO SLX FC-M7100-1 32T 2-PIECE-CRANK | SHIMANO FC-MT510-1 32T 2-PIECE-CRANK |
| Cassette | 12 SPEED 11-51T | 12 SPEED 11-51T |
| Chain | KMC NEW X-12 | KMC NEW X-12 |
| Bottom Bracket | SHIMANO BB-MT500-PA | SHIMANO BB-MT500-PA |
| Brakes | SHIMANO MT400 HYDRAULIC DISC BRAKE | SHIMANO BL-MT201 |
| Brake Levers | SHIMANO MT400 HYDRAULIC DISC BRAKE | SHIMANO BL-MT201 |
| Rotors | FRONT:180mm REAR:160mm CENTER-LOCK | SHIMANO SM-RT10 F:180mm R:160MM CENTERL LOCK |
| Seatpost | ENTITY XPERT, 27.2x350mm | ENTITY XPERT, 27.2x350mm |
| Saddle |
ENTITY VOID SADDLE |
ENTITY VOID SADDLE |
Geometry
| S - 27.5" | M - 27.5" | M - 29" | L - 29" | XL - 29" | |
|---|---|---|---|---|---|
| Stack | 596.6 | 615 | 633.2 | 651.6 | 670 |
| Reach | 410 | 430 | 430 | 450 | 470 |
| Headtube Angle | 67 | 67 | 67 | 67 | 67 |
| Headtube Length | 100 | 120 | 100 | 120 | 140 |
| Seattube Angle | 73 | 73 | 73 | 73 | 73 |
| Seattube Length | 380 | 420 | 420 | 460 | 500 |
| Toptube (Effective) | 569 | 594.6 | 597.7 | 621 | 649.15 |
| Chainstay Length | 428 | 425 | 435 | 435 | 435 |
| Wheelbase | 1060.94 | 1134.8 | 1149.5 | 1176.9 | 1204.76 |
| BB Height | 308 | 308.5 | 307.5 | 307.5 | 304.5 |
| BB Drop | 45 | 45 | 65 | 65 | 65 |
| Standover | 690.9 | 729.2 | 730.8 | 763.7 | 779.2 |
