Polygon
Polygon Path X4 Gravel Bike
Color
Size
Availability
Click & Collect
Polygon Path X4 Gravel Bike
Cream / S
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609EXPLORE DIFFERENT PATH
Nimble without compromising its handling
Comes with flared drop bar, resulting a narrower position that improves agility without compromising its handling on wider drops. With its 420-440mm length of handlebar, it gives you a little extra control when getting through light off-road.
Better acceleration with proper chainstay and wheelbase length
Accompanied with proper chainstay and wheelbase length, Path X provides you a better acceleration for riding efficiency.
Rough conditions won’t stop us
With its full carbon fork to smooth out the ride, and Hydraulic Disc Brakes that let you experience a smooth and powerful braking performance; believe me, there’s no condition that can stop you to explore more.
Gravel-ready tires
Its versatile tread design adapted to be used on larger gravel wheels max 42c. They're fast and great on tarmac, dirt road, pavements, and gravel path.
Ready for adventure!
Bonus! Its 420-440 mm handlebar length, gives you more room for bag bike. Get through everywhere with its fender and carrier ready.
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 568.9 | 593.8 | 623.5 | 652.8 |
| Reach | 367.2 | 379.7 | 395.3 | 410.4 |
| Headtube Angle | 70 | 71.5 | 71.8 | 72 |
| Headtube Length | 140 | 160 | 190 | 220 |
| Seattube Angle | 74.5 | 74 | 73.5 | 73 |
| Seattube Length | 430 | 470 | 515 | 560 |
| Toptube (Effective) | 525 | 550 | 580 | 610 |
| Chainstay Length | 425 | 425 | 425 | 425 |
| Wheelbase | 1016.9 | 1022.8 | 1044.9 | 1067.5 |
| BB Height | 276.5 | 276.5 | 276.5 | 276.5 |
| BB Drop | 78 | 78 | 78 | 78 |
| Standover | 687.5 | 726 | 768.41 | 809.9 |
