Your all-day choice for all-urban terrains
Way far from home. Kalosi Miles is an electric hybrid bike that combines durability, comfort, and efficiency for longer, faster, and more comfortable cycling on urban roads as well as uneven or semi-off-road terrain. Bringing extra comfort so you can enjoy your trip for a loooong time and take you way far from home. Because you're exploring your comfort zone.
Our pedal assist system will multiply your effort up to max 25 km/h with 5 assist variations. Enjoy flat hills and smooth paved roads up to 120 km of range when fully charged.
Comes with its integrated battery, Kalosi Miles is a perfect choice for your trouble-free maintenance commuting vehicle. It's water-resistant! You don't have to worry when it rains or goes through puddles.
The range of the Kalosi Miles with assist covers up to 120 km when the battery is full. Actual mileage may vary due to a number of other factors, such as terrain conditions, load on the bike, and state of the battery.
With its suspension fork to smooth out the ride, and Hydraulic Disc Brakes that let you experience a smooth and powerful braking performance; believe me, there’s no condition that can stop you to explore more.
Accompanied with low rolling resistance tires to reduce the energy loss as a tire rolls, decreasing the required rolling effort. Enabling you to get wherever you’re heading to faster than before.
Extra features to customize your commute! We bring the adjustable stem to optimize your riding position
Now you can connect our newest e-bike, Kalosi Miles, to our application; Polygon E-bike Apps. With its Bluetooth feature, you can track your miles. Life is easier from now on.
Specifications
| Frame | ALX URBAN-COMMUTING |
|---|---|
| Fork | SR SUNTOUR SF20-NEX 63mm TRAVEL |
| Headset | TOKEN TK-1566RZM, ZS 56/28.6 | ZS 56/30 |
| Stem | POLYGON SPORT (ADJUSTABLE), EXT: 75mm, BB: 31.8mm |
| Handlebars | POLYGON SPORT, W: 680mm, BB: 31.8mm, B: 6degree |
| Rims | ALLOY DOUBLE WALL H:18mm W: 21mm 622-18 36H FOR TYRE 622-20/54 |
| Spokes | F: 14G STAINLESS NDS:284mm DS:286mm W/ 12mm BRASS NIPPLE / R: 13G STAINLESS NDS:248mm DS:248mm W/ 13mm BRASS NIPPLE |
| Hubs | F: ALLOY 9x100mm 36H 6B / R: BAFANG DC MOTOR 36V 250W 6B |
| Tyres | URBAN PERFORMANCE 700C |
| Shifter | SHIMANO CUES SL-U4010-R, 1x9-SPEED TRIGGER |
| Rear Derailleur | SHIMANO CUES RD-U4000 9-SPEED |
| Crankset | PROWHEEL EB01-PRO44A-S3 BK 44TX170MM |
| Cassette | SHIMANO CUES CS-LG300-9 9-SPEED 11-46T CASSETTE |
| Chain | KMC EGLIDE 9/10/11-SPEED |
| Bottom Bracket | BAFANG SR PA21.32.ST FOR BB SHELL 68MM (TORQUE SENSOR) |
| Brakes | SHIMANO MT200 HYDRAULIC DISC |
| Rotors | SHIMANO RT26, 180MM |
| Seatpost | POLYGON SPORT, DxL: 30.9 x 350mm |
| Saddle | LINC EASE, STEEL ø7mm |
| Pedals | ONE PIECE PP FLAT |
| Motor | BAFANG REAR MOTOR DC MOTOR 36V 250W |
| Battery | GREENWAY ZZ618 520Wh LG21700 3PIN M6.6 |
| Sensor | (TORQUE SENSOR) BAFANG SR PA21.32.ST |
Geometry
| M | L | |
|---|---|---|
| Height | 160-170cm | 170-180cm |
| Stack | 621 | 630.5 |
| Reach | 415 | 440 |
| Headtube Angle | 73 | 73 |
| Headtube Length | 120 | 129 |
| Seattube Angle | 74 | 74 |
| Seattube Length | 431 | 470 |
| Toptube (Effective) | 593 | 621 |
| Chainstay Length | 445 | 445 |
| Wheelbase | 1091 | 1119 |
| BB Height | 294.5 | 294.5 |
| BB Drop | 70 | 70 |
| Standover | 521 | 748 |
Warranty
The bicycle frame warranty is valid for 5 (five) years from the date of purchase. For batteries and motors, it is valid for 2 (two) years from the date of purchase. Check the Polygon Bikes website for more information.
