Unmatched performance in an SL e-trail bike

We’re proud to unveil the latest evolution in our lineup: the Collosus TLE. Born from a passion to push the limits of our Collosus platform, the TLE was designed to elevate the trail experience for riders like you. Drawing inspiration from the success of the Collosus N and DH models, the TLE reintroduces carbon construction and integrates our Independent Floating Suspension (IFS) system—refined to be lighter, stiffer, and more efficient than ever. The goal? Deliver unmatched performance without compromise. Years of development and rider feedback shaped the Collosus TLE into more than just a bike; it’s a companion built for progress. With a custom-tuned ride feel and dialed-in suspension kinematics, it balances anti-squat, anti-rise, and leverage curve to deliver precise climbing efficiency, confident braking, and plush responsiveness on every descent. Built around a full 29er platform, the TLE features Fox-tuned shocks and a versatile shock yoke, offering extensive adjustability to match your style. Practical touches like tailgate protection, generous chainstay coverage, and internal cable routing complete a clean, quiet ride on any trail. The TLE is also future-ready, with Bosch motor compatibility, a range extender option, and a Bosch PowerMore 250Wh battery included as standard—ready to take on long rides and epic adventures alike. The Collosus TLE is more than a new model—it’s a statement of our commitment to progress, performance, and the journey ahead. Experience what’s next in full-suspension carbon trail bikes.

Robust IFS Linkage:
The main part of the IFS system is the double link at the bottom of the seat tube, on the TLE we separated the links which gives us more freedom to keep the same anti squat, which was all dictated by the characteristics of the previous model.

A ride that's balance, powerful & Light:
With a rear end length of 450mm, the Collosus TLE delivers a well-balanced ride. The longer chainstays are designed to seamlessly accommodate the Bosch Performance Line SX motor, providing a powerful 55 Nm of torque paired with a 400 Wh battery. It climbs with ease and descends with the confidence of a full enduro bike.

Smart Design, Built-in Convenience:
From a 750ml bottle fitment to Power More range extender compatibility with a 250Wh battery included, every detail is built for convenience. The top tube blends form and function, letting riders check sag while seated. With internal cable routing and dropper post integration, the Collosus TLE stays clean and purpose-driven.

UDH:
With the UDH dropouts, the Collosus TLE is now compatible with T-Type drivetrains for seamless integration with modern shifting systems.

34.9mm Seatpost Diameter:
Now featuring a 34.9mm seat tube diameter to support stronger, more reliable dropper posts.

Double row bearings for added durability:
The frame runs 3901 double row sealed bearings, ensuring unparalleled consistency across all main pivot points, including the shock yoke.

Specifications:

Collosus TLE 8 Collosus TLE 0
Frame ACX e-MTB ACX e-MTB
Fork MARZOCCHI BOMBER Z1, 160mm TRAVEL, OFFSET: 44mm, AIR SPRING, RAIL DAMPER,REBOUND ADJUST FOX PERFORMANCE ELITE 36, FLOAT EVOL, 160mm TRAVEL, OFFSET: 44mm, HSC-LSC, HSR-LSR, W/ FENDER
Rear Shock MARZOCCHI BOMBER AIR, E2E: 210x55mm FOX FLOAT X PERFORMANCE ELITE, E2E: 210x55mm
Headset FSA NO.42/47/ACB, IS 42/28.6 | IS 52/40 FSA NO.42/47/ACB, IS 42/28.6 | IS 52/40
Stem POLYGON EXPERT, EXT: 35mm, BB: 35mm, R/D: 0mm RACE FACE AFFECT R 35, EXT: 40mm, BB: 35mm, R/D: 0mm
Handlebars POLYGON EXPERT, W: 780mm, BB: 35mm, R/D: 30mm, B: 9degree RACE FACE CHESTER 35, W: 780mm, BB: 35mm, R/D: 35mm, B: 8degree
Rims F: ALLOY DOUBLE WALL FV H:18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE / R: ALLOY DOUBLE WALL FV H:18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE F: ALLOY DOUBLE WALL FV H:18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE / R: ALLOY DOUBLE WALL FV H:18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE
Spokes F: STAINLESS 14G NDS:292mm DS:294mm W/ 12mm BRASS NIPPLE / R: STAINLESS 14G NDS:294mm DS:292mm W/ 12mm BRASS NIPPLE F: STAINLESS 14G NDS:292mm DS:294mm W/ 12mm BRASS NIPPLE / R: STAINLESS 14G NDS:294mm DS:292mm W/ 12mm BRASS NIPPLE
Hubs F: DT SWISS 370 HYBRID CLASSIC 15x110mm 32H 6-BOLT / R: DT SWISS 370 HYBRID CLASSIC 12x148mm 32H 6-BOLT FOR XD DRIVER F: DT SWISS 370 HYBRID CLASSIC 15x110mm 32H 6-BOLT / R: DT SWISS 370 HYBRID CLASSIC 12x148mm 32H 6-BOLT FOR XD DRIVER
Tyres MAXXIS DISSECTOR 29"x2.40" 622x65, TLE MAXXIS DISSECTOR 29"x2.40" 622x65, TLE
Shifter SRAM EC AXS POD CONTROLLER, 1x12-SPEED TRIGGER SRAM EC AXS POD CONTROLLER, 1x12-SPEED TRIGGER
Rear Derailleur SRAM GX EAGLE T-TYPE AXS SRAM XX EAGLE T-TYPE AXS
Crankset SRAM CR T-TYPE, 34T SRAM XX CARBON T-TYPE, 34T
Cassette SRAM GX EAGLE T-TYPE 10-52T XD DRIVER SRAM XX EAGLE T-TYPE 10-52T XD DRIVER
Chain SRAM GX EAGLE T-TYPE SRAM XX T-TYPE
Brakes MAGURA MT7 HYDRAULIC DISC MAGURA MT7 HYDRAULIC DISC
Brake Levers MAGURA HC3 MAGURA HC3
Rotors MAGURA MDR C, 203MM 6-BOLT MAGURA MDR C, 203MM 6-BOLT
Seatpost TRANZ X JD-YSP39KL 170mm (S, M) / 200mm (L, XL) TRAVEL, DxL: 34.9 x 495mm (S, M) / 556mm (L, XL)
Seatpost

TRANZ X JD-YSP39KL 170mm (S, M) / 200mm (L, XL) TRAVEL, DxL: 34.9x495mm (S, M) / 556mm (L, XL)
Saddle XTENT, CR-MO ø7mm XTENT, CR-MO ø7mm
Motor BOSCH PERFORMANCE LINE SX BDU3145 BOSCH PERFORMANCE LINE SX BDU3145
Battery BOSCH COMPACTTUBE 400 FIXED MOUNT HORIZONTAL BOSCH COMPACTTUBE 400 FIXED MOUNT HORIZONTAL
Sensor BOSCH RIM MAGNET BOSCH RIM MAGNET



Geometry

S M L XL
Stack 614 619 628 642
Reach 435 461 481 501
Headtube Angle 64.1 64.1 64.1 64.1
Headtube Length 90 95 105 120
Seattube Angle 76.6 76.6 76.6 76.6
Seattube Length 390 400 415 430
Toptube (Effective) 586 607 627 648
Chainstay Length 450 450 450 450
Wheelbase 1215 1242 1266 1293
BB Height 343 343 343 343
BB Drop 35 35 35 35
Standover 748 757 764 770



Sizing


 S M L XL
Height (cm) 155 - 165 165 - 175 175 - 185 185 - 195



FAQ:

What is the IFS Suspension System?

The main part of the IFS system is the double link at the bottom of the seat tube, on the Collosus TLE we separated the links which gives us more freedom to keep the same anti squat, which was all dictated by the characteristics of the previous model.

Is the Bike Coil Shock Compatible?

Yes, the Collosus TLE is compatible with a coil shock. It comes stock with 140mm rear travel paired with a Fox Float X air shock (R model) and a 160mm Fox fork up front, matched with a confidence-inspiring 64° head angle. You can also “over-fork” it by 10mm to bump the fork travel up to 170mm if desired. Shock hardware sizes are 25mm x 8mm (front) and 15mm x 8mm (rear yoke).

What's the Max tyre size?

Max tyre is 2.60"

Can the Bike Be setup Mullet?

No the bike is 29" only.

How do I charge the battery, how long does it take to charge?

The battery can be charged either installed in the bike, via the charging port on the left side in front of the motor, or detached from the bike using the additional connection port supplied with the charger. Charging to 50% takes. approximately 2 hours, while a full charge requires 4 hours.

Are the electronic components weatherproof?

Yes. The BOSCH Performance Line SX systems are waterproof for use under normal riding conditions. Please do not use a high-pressure washer to clean your bike.

What is the range?

The range of any e-MTB depends on many variables, including terrain, gradients, rider weight, assistance mode, rider input, ambient temperature, etc. While 125 km adventures* are definitely achievable aboard the Collosus TLE, we recommend using the Range overview on the display for the best estimate. The range overview is recalculated continuously by calculating speed, rider behavior and power consumption. This means that range overview makes a prediction, which can vary depending on these different factors.

(*) With ECO mode

How much does the bike weigh?

Size M = 22.2 kg

(*) Applies to both Collosus TLE0 and Collosus TLE8 models.
