Polygon Cascade 3 Hardtail MTB
Color:
Color
Size:
Size
Quantity:
Click & Collect
Pickup currently unavailable at Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Polygon Cascade 3 Hardtail MTB
Red/Black / S - 27.5"
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Pickup currently unavailable
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Pickup available, usually ready in 5+ days
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609THE SORCERER
The beginning of loving mountains
Our all-time sorcerer -- Cascade, born for you who are planning to go for recreational riding on the weekends and feel mountains. The Cascade MTB is built with a lightweight and durable AL6 frame with modern geometry for a more comfortable ride. The component spec includes: 27.5” wheels for less rolling resistance, a 100mm travel suspension fork to smooth out the bumps while riding down fire roads, and disc brakes to keep riders in control. Be ready to be enchanted with our sorcerer and start loving mountains even more.
Specifications
| Frame | AL6 XC SPORT FRAME |
|---|---|
| Fork | SUNTOUR XCE28 100mm TRAVEL |
| Headset | ZERO STACK (ZS) THREADLESS, ZS 44/28.6 | 44/30 |
| Handlebars | STEEL, W: 680MM, B: 31.8MM, R/D: 40MM |
| Stem | ENTITY ALLOY, E: 45MM, B: 31.8MM |
| Seatpost | ENTITY, 27.2x350mm |
| Saddle | MTB SADDLE, STEEL ø7mm |
| Shifter | SHIMANO ST-EF41, 3x7 SPEED TRIGGER |
| Crankset | STEEL CRANK 42x34x24T |
| Cassette | SHIMANO MF-TZ500 7-SPEED 14-28T FREEWHEEL |
| Chain | KMC HV-500 |
| Rear Derailleur | SHIMANO RD-TY300 6/7-SPEED DIRECT ATTACH |
| Bottom Bracket | CARTRIDGE BEARING W/ CAGED BEARING & 119mm SQUARE AXLE |
| Pedals | PP CAGE W/ REFLECTOR |
| Rims | ALLOY DOUBLE WALL AV H: 20 584x20 32H FOR TIRE 584-28/62 DISC |
| Hubs | F: ALLOY DISC BRAKE QR9x100mm 32H 6B / R: ALLOY DISC BRAKE QR9x135mm 32H 6B FOR FREEWHEEL |
| Tyres | DELI 27.5"x2.1" 584x54 |
| Brake Levers | SHIMANO ST-EF41 |
| Brakes | TEKTRO MD-M280 |
| Rotors | TEKTRO TR160-24 160mm 6-BOLTS |
Geometry
| S | M | |
|---|---|---|
| Height (cm) | 152-165 | 162-175 |
| Seat Tube Length (A) | 406 | 456 |
| Seat Tube Angle (B) | 73 | 73 |
| Effective Seat Tube Angle (C) | 73 | 73 |
| Head Tube Length (D) | 100 | 105 |
| Head Tube Angle (E) | 69 | 69 |
| Effective Top Tube (F) | 565 | 585 |
| Bb Height (G) | 303 | 303 |
| Bb Offset (H) | 47 | 47 |
| Chainstay Length (I) | 430 | 429 |
| Wheelbase (J) | 1065.7 | 1086.1 |
| Frame Reach (K) | 383.7 | 402.2 |
| Frame Stack (L) | 593.1 | 597.8 |
| Standover Height (M) | 700 | 742 |
