Marin Team Marin 1 Hardtail Mountain Bike
Color
Size
Click & Collect
Marin Team Marin 1 Hardtail Mountain Bike
Solid Green / S
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609CROSS COUNTRY RACING
FUN TRAINING & TRAIL RIDING
XC LIGHT WITH TRAIL RIDING CAPABILITY
We made the Team Marin to be lightning-fast, super composed in the rough-and-tumble of spicy singletrack and perfectly in control up, along and down. It packs all the roll-up-your-sleeves tough of a trail bike and the zip you’d expect from an XC racer to perfectly blend speed with fun. Because who said XC had to be so serious?!
Champagne dreams on a cola budget. The Team Marin 1 brings XC-racer performance to a privateer price-point, all whilst staying super fun and super capable in the singletrack.
We started with a high-end Series 4 aluminum frame and fast-rolling 29” wheels and then added a capable RockShox Judy Silver fork, 12-speed Shimano drivetrain, Shimano hydraulic brakes and Vee Tire rubber to create a super fun, super affordable XC trail shredder.
Specifications
| Frame | All New Series 4 6061 Aluminum, 29" Wheels, Superlight Aluminum, Post-Mount Rear Brake, Internal Shifter and Dropper Post Routing, 148x12mm Boost Thru-Axle |
|---|---|
| Fork | RockShox Judy Silver TK, 120mm Travel, Alloy Tapered Steerer, Solo Air Spring, 110x15mm Boost Spacing, Maxle Stealth, 51mm Offset |
| Headset | FSA No 42ACB, 1 1/8" x 1 1/2” |
| Stem | Marin 3D Forged Alloy, 35mm |
| Handlebars | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back |
| Grips | Marin Single Clamp Locking |
| Rims | Marin Aluminum Double Wall, 29mm Inner, Sleeve Joint, Disc Specific, Tubeless Compatible |
| Spokes | 14g Black Stainless Steel |
| Front Hub | Forged Aluminum, 110x15mm, Disc, 32H |
| Rear Hub | Forged Aluminum, 148x12mm, Disc Specific, 32H |
| Tyres | Vee Tire, Rail Rocco XC, 29x2.3", Dual Control Compound, Folding Bead, Tubeless Ready |
| Shifter | Shimano Deore, SLM6100, 12-Speed |
| Rear Derailleur | Shimano Deore, RDM6100, 12-Speed |
| Crankset | Forged Alloy 1x12, Hollow Spindle, Steel Narrow Wide 32T Chainring |
| Cassette | SunRace, 12-Speed, 11-51T |
| Chain | KMC X12 |
| Bottom Bracket | External Sealed Cartridge Bearings |
| Front Brake | Shimano BR-MT200 Hydraulic Disc, 180mm Rotor |
| Rear Brake | Shimano BR-MT200 Hydraulic Disc, 160mm Rotor |
| Brake Levers | Shimano BL-MT201 |
| Seatpost | Marin Alloy, 30.9mm |
| Saddle | Marin Speed Concept |
| Pedals | Nylon Platform |
| Extras |
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 616 | 628 | 637 | 646 |
| Reach | 410 | 430 | 450 | 485 |
| Headtube Angle | 66.5 | 66.5 | 66.5 | 66.5 |
| Headtube Length | 97 | 110 | 120 | 130 |
| Seattube Angle | 74 | 74 | 74 | 74 |
| Seattube Length | 381 | 431 | 482 | 520 |
| Toptube (Effective) | 587 | 610 | 633 | 670 |
| Chainstay Length | 425 | 425 | 425 | 425 |
| Wheelbase | 1122 | 1147 | 1171 | 1210 |
| BB Height | 320 | 320 | 320 | 320 |
| BB Drop | 60 | 60 | 60 | 60 |
| Standover | 680 | 709 | 756 | 789 |
| Fork Offset | 44 | 44 | 44 | 44 |
SERIES 4 ALUMINUM FRAME
The Team Marin features Series 4 aluminum frames, with advanced tube forming for minimal weight, 3D forged dropouts, flat-mount disc tabs, full internal cable routing, and a boost 148mm thru axle.
INTERNAL DROPPER POST ROUTING
The Team Marin frame includes internal routing in the front triangle for a clean, fast appearance, and allowing for Team Marin 1 owners to upgrade to an internal dropper post if they desire.
29” WHEELS AND 2.35” TIRES FOR MAXIMUM SPEED
29” wheels and 2.35” XC tires ensure maximum grip and float over obstacles to maintain speed so you can pick up those personal records and keep ahead of the pack.
