Marin Stinson 1 Hybrid Bike
Color
Size
Click & Collect
Marin Stinson 1 Hybrid Bike
Black / S
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609The Stinson is an updated take on the classic cruiser design for casual and comfortable path riding. Comfort Control Geometry allows riders to touch the ground with their foot for confident and safe riding and stopping.
The Stinson brings a new level of comfort and control to your ride. This model has a lightweight Series 1 aluminum frame with low standover, an ergonomic handlebar, plush saddle, and versatile, high-volume 27.5” tires with mixed tread for control on a variety of surfaces. Design features include our Comfort Control Geometry with upright seating and the ability to touch the ground with the forefoot, while maintaining proper saddle height for pedaling efficiency.
BIKE PATH CRUISING
CASUAL FITNESS
The Stinson is an updated take on the classic cruiser design for casual and comfortable path riding. Comfort Control Geometry allows riders to touch the ground with their foot for confident and safe riding and stopping.
Specifications
| Frame | Series 1 Comfort, 6061 Aluminum, 27.5” Wheels, Disc Specific, Comfort Control Geometry, Kickstand Mount, Fender and Rack Mounts |
|---|---|
| Fork | CrMo Steel, Straight Blade, Disc Specific, Fender and Rack Eyelets |
| Headset | FSA, TH No.10P |
| Stem | Marin Alloy |
| Handlebars | Marin Alloy, 60mm Rise, 30˚ Backsweep |
| Grips | Marin County |
| Rims | Marin Aluminum Double Wall, Disc Specific |
| Spokes | 14g Stainless Steel |
| Tyres | Vee Tire Co. Speedster, 27.5”x2.35”, Puncture Protection |
| Shifter | Shimano Altus 7-Speed RapidFire |
| Rear Derailleur | Shimano Tourney, 7-Speed |
| Crankset | Alloy Crank, Steel 38T Chainring, Ring Guard |
| Cassette | SunRace 7-Speed, 11-34T |
| Chain | KMC Z8 |
| Bottom Bracket | Sealed Cartridge Bearings, Square Taper |
| Front Brake | Clark's CMD-23 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor |
| Rear Brake | Clark's CMD-23 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor |
| Brake Levers | Shimano w/ Integrated Shifters |
| Seatpost | Marin Alloy, 30.9mm |
| Saddle | Marin Comfort |
| Pedals | Marin Comfort Platform |
| Extras |
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 628.2 | 646.9 | 665.5 | 679.4 |
| Reach | 340 | 355 | 370 | 381.6 |
| Headtube Angle | 68.5 | 68.5 | 68.5 | 68.5 |
| Headtube Length | 210 | 230 | 250 | 265 |
| Seattube Angle | 67 | 67 | 67 | 67 |
| Seattube Length | 382 | 406 | 444 | 470 |
| Toptube (Effective) | 606.7 | 629.6 | 652.5 | 670 |
| Chainstay Length | 485 | 485 | 485 | 485 |
| Wheelbase | 1083.9 | 1106.2 | 1128.6 | 1145.65 |
| BB Height | 276.5 | 276.5 | 276.5 | 276.5 |
| BB Drop | 68 | 68 | 68 | 68 |
| Standover | 618.44 | 618.48 | 674.72 | 675.89 |
| Fork Offset | 40 | 40 | 40 | 40 |
Seatpost Diameter: 30.9mm
Handlebar Width: 700mm
Stem Length: 45mm
Crank Length: 170mm
