The Headlands 3, the creme de la creme, the king of the crop - our top tier build for gravel nirvana. The same carbon frame and fork with our in frame Bear Box storage is now adorns with a full 1 x 13 Sram Rival wireless transmission, Sram Rival hydraulic disc brakes, a TransX dropper post and a stiff, light and efficient Novatec G24 carbon wheelset. A Marin finishing kit tops off the boutique build list - we're very excited for this one!

Key Upgrades

  • SRAM Rival 13-speed wireless drivetrain
  • Novatec G24 Carbon Wheelset

Fully loaded bikepacking, fast and light off-road adventures, gravel and CX racing… or simply exploring your favorite tracks and trails. The Marin Headlands is a high tech, high-spec carbon fiber gravel and adventure bike that’s made to be lightning-fast, confidence-inspiring and super comfortable on all surfaces.

We’ve taken our own unidirectional carbon fiber frame, added mountain bike-inspired geometry, loads of tire clearance and a whole heap of mounting points for gear and fenders to create a super versatile, super capable all-terrain dart of a bike. Go 700c with room for up to 45mm tires or 650b up to 47mm.

UNIDIRECTIONAL CARBON FIBER FRAME

The Headlands has a unidirectional carbon fiber frame designed to meet the demands of modern gravel and endurance riders and racers with large tire clearance, a 142x12mm thru-axle, and multiple frame eyelets for customized hydration and frame bag needs.

TIRE CLEARANCE

The Headlands was designed with clearance for up to 700Cx45 or 650Bx50 tires to handle even the roughest “roads.”

INTERNAL DROPPER COMPATIBILITY

The Headlands features a seattube port for internal dropper routing, with the Headlands 2 coming stock with a 105mm/85mm dropper post.

REMOVABLE SEATSTAY BRACE

The removable seat stay brace makes it super easy to add fenders for foul weather riding and commuting, while maintaining a clean smooth look when you don’t need the coverage.

Frame Unidirectional Carbon Beyond Road Platform, 1x Drivetrain Specific, 700c x 50mm Compatible, Flat Mount Disc, 142x12mm Thru-Axle, UDH Dropout, Internal Housing Routing, Mudguard and Rear Carrier Mounting, Bear Box Downtube Storage
Fork Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Headset FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Stem Marin 3D Forged Alloy
Handlebars Marin Butted Alloy, Compact 16º Flared Drop
Grips Marin Shock Absorbing Tape
Rims Novatec, G24 Carbon, 24mm Internal, 24 Hole, Tubeless Compatible
Spokes Double Butted Stainless
Tyres Vee Tire Co., Quikstyk, 700x45,Folding Bead, Tubeless Compatible
Shifter SRAM Rival E1 XPLR, Wireless
Rear Derailleur SRAM Rival XPLR, 13-Speed
Crankset SRAM Rival XPLR, 40T
Cassette SRAM CS-XG-1351, 10-46T
Chain SRAM Rival 13-Speed
Bottom Bracket SRAM Dub BSA
Front Brake SRAM Rival XPLR Flat-Mount Hydraulic Disc, 160mm Rotor
Rear Brake SRAM Rival XPLR Flat-Mount Hydraulic Disc, 160mm Rotor
Brake Levers SRAM Rival XPLR w/ Inegrated Shifter
Seatpost TranzX YSP38J, Size 49-54 70mm, Size 56-60 110mm Travel, 27.2mm
Saddle Marin Beyond Road Concept Elite
Pedals -
Extras Bolt-On Thru-Axles F and R

Geometry

49 52 54 56 58 60
Stack 550.3 565.7 581.8 600.8 619.7 638.7
Reach 370 372.8 372.7 386.4 411.4 425.8
Headtube Angle 70.5 70.5 70.5 70.5 70.5 70.5
Headtube Length 110 125 140 160 180 200
Seattube Angle 74.5 74 73.5 73.5 73.5 73.5
Seattube Length 440 470 490 410 430 550
Toptube (Effective) 520 531 541 559 590 610
Chainstay Length 420 420 420 420 420 420
Wheelbase 1001 1008 1013 1032 1064 1086
BB Height 289 289 289 289 289 289
BB Drop 76 76 76 76 76 76
Standover 684 701 705 725 745 765
Fork Offset 50 50 50 50 50 50
Stem Length 60 60 60 60 70 70
Handlebar Width 420 420 420 440 440 440
Crank Length 170 170 175 175 175 175
