Marin Gestalt X10 Gravel Bike
Color
Size
Click & Collect
Marin Gestalt X10 Gravel Bike
Grey/Green / S
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609The Marin Gestalt X is our hard-charging, rough-and-rowdy take on what gravel and adventure bikes can do. Break off the fire road, down the singletrack and charge further and faster than ever before. All while keeping the versatility, challenge and fun of a bike with drop handlebars.
Gestalt X models are built with a longer-than-the-usual wheelbase, slack-like-your-mountain-bike head angle, low-slung frame, wide bars, short stem, big and chunky tires with room for up to 50mm on 700c or 54mm with a 650b wheelset.
Is it a gravel bike? Is it a drop bar mountain bike? Is it a bikepacking bike? Yes to all of the above! Who cares about definitions and pigeonholes? All you need to know is that the XR stands for eXtra Rad!
The Gestalt X is our hard-charging, rough-and-rowdy take on what gravel and adventure bikes can do. Break off the fire road, down the singletrack and charge further and faster than ever before. All while keeping the versatility, challenge and fun of a bike with drop handlebars.
The Gestalt X is built with a longer-than-the-usual wheelbase, slack-like-your-mountain-bike head angle, low-slung frame, wide bars, short stem, big and chunky tires with room for up to 50mm on 700c or 54mm with a 650b wheelset.
The Gestalt X10 means extra fun at an extra awesome price. Pick one up and you’ll be riding our MTB-inspired, Series 3 aluminum Gestalt X frame and a whole heap of tough and capable kit, including a 10-speed microSHIFT groupset, cushy and grippy 45mm wide Vee Tire Co tires, Tektro disc brakes and plenty of kick-ass Marin components.
Specifications
| Frame | Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle |
|---|---|
| Fork | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
| Headset | FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| Stem | Marin 3D Forged Alloy |
| Handlebars | Marin Butted Alloy, Compact 16º Flared Drop |
| Bartape | Marin Shock Absorbing Perforated Tape |
| Rims | Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific |
| Spokes | 14g Black Stainless Steel |
| Front Hub | Forged Aluminum Alloy, Disc, 32H |
| Rear Hub | Forged Aluminum Alloy, Disc, 32H |
| Tyres | Vee Tire Co., Quickstyx, 700x45, Tubeless Compatible |
| Shifter | microSHIFT SWORD, 10-Speed |
| Rear Derailleur | microSHIFT SWORD 10-Speed Wide-Range |
| Crankset | Forged Alloy 1x10, Hollow CrMo Spindle, Narrow Wide 42T |
| Cassette | microSHIFT SWORD 10-Speed, 11-48T |
| Chain | KMC X10 |
| Bottom Bracket | External Sealed Cartridge Bearings |
| Front Brake | Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor |
| Rear Brake | Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor |
| Seatpost | Marin Alloy, 27.2mm |
| Saddle | Marin Beyond Road Concept |
| Pedals | - |
| Extras | Bolt-On Thru-Axles F and R |
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Stack | 547.6 | 566 | 589.1 | 621.5 |
| Reach | 400 | 420 | 440 | 460 |
| Headtube Angle | 67.5 | 67.5 | 67.5 | 67.5 |
| Headtube Length | 130 | 150 | 175 | 210 |
| Seattube Angle | 75 | 74 | 74 | 74 |
| Seattube Length | 460 | 485 | 505 | 530 |
| Toptube (Effective) | 546.7 | 582.3 | 608.9 | 638.2 |
| Chainstay Length | 425 | 425 | 425 | 425 |
| Wheelbase | 1065.2 | 1092.8 | 1122.4 | 1155.6 |
| BB Height | 282.5 | 282.5 | 282.5 | 282.5 |
| BB Drop | 80 | 80 | 80 | 80 |
| Standover | 678.6 | 687.7 | 708.6 | 734.5 |
| Fork Offset | 50 | 50 | 50 | 50 |
SERIES 3 FRAME
The Gestalt X features a butted and formed Series 3 6061 aluminum frame with internal routing, 142x12mm thru-axles, flat mount disc brakes, and rack and fender eyelets.
BEYOND ROAD GEOMETRY
The Gestalt X takes our Beyond Road Geometry to the next level of aggressive road and dirt exploration with a blend of endurance road handling and mountain bike sensibilities.
DISC BRAKES
The Gestalt X features the latest flat mount disc brake standard for smooth, controlled stopping in all conditions with minimal maintenance.
TIRE CLEARANCE
The Gestalt X frame and fork has clearance for up to up to 700Cx45 or 650Bx47 Road Plus tires.
BRAZE-IN CABLE ROUTING
New braze-in cable/hose routing is seek, clean, and rattle-free.
