Marin Gestalt 1 Gravel Bike
Color:
Color
Size:
Size
Quantity:
Click & Collect
Pickup currently unavailable at Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Marin Gestalt 1 Gravel Bike
White / 50cm
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Pickup currently unavailable
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Pickup available, usually ready in 5+ days
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609ADVENTURE ROAD RIDING
LONG DISTANCE COMMUTING
ENDURANCE AND ALL-WEATHER PAVEMENT
The Gestalt is for the drop bar rider that doesn’t want to stick to pavement, and can’t help but get dirty no matter the route. Long distance commuters and all-weather riders will appreciate the fender and rack mounts and the sure stopping disc brakes, and the larger volume tires are right at home on that unexpected detour.
Key upgrades over Gestalt:
- Series 3 Beyond Road frame w/highly formed & butted custom tubeset
- Marin full carbon fork
- Shimano Sora 2x9 drivetrain
- Tektro mechanical disc brakes
Specifications
| Frame |
Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle |
|---|---|
| Fork | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
| Headset | FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| Rims | Marin Aluminum Double Wall, 21mm Inner, 22mm Tall, Disc Specific, Tubeless Compatible |
| Rear Hub | Forged Aluminum Alloy, 6-Bolt Disc, 32H |
| Front Hub | Forged Aluminum Alloy, 6-Bolt Disc, 32H |
| Spokes | 14g Black Stainless Steel |
| Tyres | Vee Tire Co., Zilent, 700x35 |
| Rear Derailleur |
Shimano Sora 9-Speed |
| Front Derailleur |
Shimano Sora |
| Shifters |
Shimano Sora 2x9-Speed |
| Crankset |
Shimano R345 Octalink Compact, 50/34T |
| Bottom Bracket |
Shimano Octalink V2 Cartridge |
| Chain | KMCX9 |
| Cassette |
SunRace 9-Speed, 11-32T |
| Front Brake |
Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor |
| Rear Brake |
Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor |
| Handlebar | Marin Butted Alloy, Compact 12º Flared Drop |
| Stem | Marin 3D Forged Alloy |
| Grips | Marin Perforated Tape |
| Seatpost | Marin Alloy, 27.2mm |
| Saddle | Marin Beyond Road Concept |
| Pedals | Commute Platform |
Geometry
| 50 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|
| A. Stack | 552 | 568 | 582 | 601 | 620 | 641 |
| B. Reach | 367 | 372 | 377 | 387 | 402 | 404 |
| C. Headtube Angle | 71.5 | 71.5 | 71.5 | 71.5 | 71.5 | 71.5 |
| D. Headtube Length | 120 | 135 | 150 | 170 | 190 | 210 |
| E. Seattube Angle | 74.5 | 74 | 73.5 | 73.5 | 73.5 | 73 |
| F. Seattube Length | 460 | 480 | 500 | 520 | 540 | 560 |
| G. Toptube Effective | 520 | 535 | 550 | 565 | 585 | 600 |
| H. BB Height | 276 | 276 | 276 | 276 | 276 | 276 |
| I. BB Drop | 78 | 78 | 78 | 78 | 78 | 78 |
| J. Chainstay | 432 | 432 | 432 | 432 | 432 | 432 |
| K. Wheelbase | 1008 | 1014 | 1024 | 1040 | 1060 | 1070 |
| L. Standover Height | 714 | 732 | 755 | 775 | 794 | 814 |
| M. Fork Offset | 50 | 50 | 50 | 50 | 50 | 50 |
| Seatpost Diameter | 27.2 | |||||
| Handlebar Width | 420 | 420 | 440 | 440 | 460 | 460 |
| Stem Length | 70 | 70 | 90 | 90 | 110 | 110 |
| Crank Length | 170 | 170 | 175 | 175 | 175 | 175 |
