+3532840609The El Roy is the ultimate aggressive steel hardtail that’ll get you to the top, and then really shine on the way down, with a spicy mix of progressive geometry and supple steel.
Features:
Wheelsize: 29"
Frame: Chromoly Steel
Sizes: Regular, Grande
Size Guide
| Size | Rider Height |
|---|---|
| Regular | 5'5" - 5'10" |
| Grande | 5'10" - 6'4" |
Specifications
| Frame | Series 3 Double Butted and Formed CrMo tubing, Integrated Drop-In Headset, External Rear Derailleur and Brake Housing, Internal Dropper Post Routing, 148x12mm Boost Rear Spacing, Post Mount Brake Mounts |
|---|---|
| Fork | Marzocchi Z1, 140mm Travel, EVOL Air Spring, GRIP Damper w/ Sweep Adjust, Kabolt 110 Axle, 44mm Offset |
| Rims | Marin, Double Wall Alloy, 29mm Inner, Welded Joint, Disc Specific, 32H, Tubeless Compatible |
| Rear Hub | Shimano HB-MT410B, 148x12mm, Disc, Microspline Freehub Body |
| Front Hub | Shimano HF-MT410B, 110x15mm, Disc |
| Spokes | 14g Black Stainless Steel |
| Front Tyre | Maxxis Assegai 29x2.5", Tubeless Compatible |
| Rear Tyre | Maxxis Assegai 29x2.5", 3C MAXX TERRA Double Down Rear, Tubeless Compatible |
| Rear Derailleur | Shimano Deore, 12-Speed, SGS |
| Shifter | Shimano Deore, M6100, 12-Speed |
| Crankset | FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing |
| Bottom Bracket | Mego EXO 73mm BSA |
| Chain | KMC X-12 Silver and Black |
| Cassette | Shimano, Deore 12-Speed, 10-51T |
| Front Brake | Shimano BR-MT420, 4-Piston Hydraulic Disc Brake, 203mm Rotor |
| Rear Brake | Shimano BR-MT420, 4-Piston Hydraulic Disc Brake, 180mm Rotor |
| Brake Levers | Shimano BL-M4100 Hydraulic Lever, I-Spec EV Compatible |
| Handlebars | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
| Stem | Marin 3D Forged Alloy, 35mm |
| Grips | Marin Grizzly, Lock On |
| Headset | FSA Orbit 40 No.42 ACB |
| Seatpost | X Fusion Manic, Regular = 150mm Travel, Grande = 170mm Travel |
| Saddle | Marin Speed Concept |
Geometry
| Regular | Grande | |
|---|---|---|
| Stack | 645 | 645 |
| Reach | 480 | 510 |
| Headtube Angle | 63 | 63 |
| Headtube Length | 120 | 120 |
| Seattube Angle | 78 | 78 |
| Seattube Length | 420 | 430 |
| Toptube Effective | 617 | 647 |
| BB Height | 318 | 318 |
| BB Drop | 65 | 65 |
| Chainstay Length | 435 | 435 |
| Wheelbase | 1252 | 1282 |
| Standover Height | 735 | 743 |
| Fork Offset | 44 | 44 |
- Seatpost Diameter: 30.9mm
- Handlebar Width: 800mm
- Stem Length: 35mm
- Crank Length: 170mm
