Marin
Marin Hidden Canyon 20" Kids Bike
Color
Availability
Click & Collect
Marin Hidden Canyon 20" Kids Bike
Teal/Pink
Unit 9, Hills Hire Centre, Johnstown Rd, Dún Laoghaire, Co. Dublin
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
012840609Warehouse
Unit 9, Hills Hire Centre,Johnstown Rd,Dún Laoghaire,Co. Dublin
+3532840609FUN!
The Bayview Trail 24” and Hidden Canyon 20” bikes are built to get kids hooked on riding with quality components and fun graphics that will last for years of neighborhood and bike park service.
SPECIFICATIONS
-
FRAME
Series 1 6061 Aluminum, 20” Wheels, IS Seatstay Disc Mounts, 135mm Dropouts
-
FRONT SUSPENSION
Steel Rigid Fork, 100mm Spacing, QR Lever
-
RIMS
Marin, Double Wall Alloy
-
HUB, REAR
Formula, 32H
-
HUB, FRONT
Formula, 32H
-
SPOKE, NIPPLES
14g Stainless Steel
-
TIRES
Multi Surface, 20”x2.125”
-
DERAILLEUR, REAR
Shimano Tourney, 7-Speed
-
DERAILLEUR, FRONT
-
-
SHIFT LEVER
Shimano Revo Twist 1x7-Speed
-
CRANKSET
Forged Alloy, 36T, 140mm, Ring Guard
-
BOTTOM BRACKET
Sealed Cartridge Bearings, Square Taper
-
CHAIN
KMC Z50
-
CASSETTE
Shimano HG20, 12-28T
-
BRAKE, FRONT
Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor
-
BRAKE, REAR
Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor
-
BRAKE LEVERS
Kids Specific Short Reach Alloy
-
HANDLEBAR
Marin Riser, 30mm Rise, 590mm Width
-
STEM
Marin Alloy, 60mm
-
GRIPS
Marin Dual Density
-
HEADSET
FSA, Threaded
-
SEATPOST
Marin Alloy, 27.2mm
-
SADDLE
Marin Kids MTB
-
PEDALS
Kids Specific Nylon
Specifications, pricing, and availability are subject to change without notice.
GEOMETRY
| ONE SIZE | |
|---|---|
| STACK | 439.39 |
| REACH | 297.66 |
| HEADTUBE ANGLE | 70° |
| HEADTUBE LENGTH | 105 |
| SEATTUBE ANGLE | 73° |
| SEATTUBE LENGTH | 308 |
| TOPTUBE EFFECTIVE | 432 |
| BB HEIGHT | 232 |
| BB DROP | 25 |
| CHAINSTAY | 380 |
| WHEELBASE | 862.79 |
| STANDOVER HEIGHT | 511.66 |
| FORK OFFSET | 33 |
| SEATPOST DIAMETER | 27.2 |
| HANDLEBAR WIDTH | 590 |
| STEM LENGTH | 45 |
| CRANK LENGTH | 140 |
All lengths in millimeters
TECHNOLOGY
ALUMINUM FRAME AND DISC BRAKES
Lightweight Series 1 6061 aluminum frames with replaceable derailleur hangers and disc brakes with size-appropriate brake levers for comfort and control.
SHIMANO DRIVETRAIN
The durable Shimano 7-speed drivetrain has the gear choices kid need to tackle trails in an easy to master package with a single front chainring and intuitive twist shifter.
