+3532840609The Marin Palisades Trail 2 is a brilliant mountain bike that offers exceptional value for money for novice riders looking to improve their skills.
With a Rockshox Judy Suspension Fork, Tektro Hydraulic disc brakes and 18 speed Shimano groupset the Palisades Trail includes some impressive features for a bike at this price-point.
Specifications:
| Frame | Series 2 6061 Aluminum, 27.5” Wheels, 135mm Forged Dropouts, Chainstay Disc Mount, Full External Housing |
| Front Suspension | RockShox Judy Silver TK, 100mm Travel, Hydraulic Lockout, Damping Adjustment, 42mm Offset |
| Rim | Double Wall Alloy |
| Hub Rear | Forged Alloy, 6-Bolt Disc, 32H |
| Hub Front | Forged Alloy, 6-Bolt Disc, 32H |
| Spokes | 14g Black Stainless Steel |
| Tires | WTB Trailboss Comp, 27.5x2.25”, Wire Bead |
| Derailleur Rear | Shimano Acera, 9-Speed |
| Derailleur Front | Shimano Altus |
| Shift Lever | Shimano Altus, 9-Speed |
| Crankset | Shimano Altus MT101, 36/22T |
| Bottom Bracket | Sealed Cartridge Bearings, Square Taper |
| Chain | KMC X9 |
| Cassette | Shimano HG-200, 9-Speed, 11-36T |
| Brakes Front | Tektro M275 Hydraulic Disc, 160mm Rotor |
| Brakes Rear | Tektro M275 Hydraulic Disc, 160mm Rotor |
| Brake Levers | Tektro M275 Hydraulic Disc |
| Handlebar | 31.8 Riser, 12mm Rise, 760mm Width |
| Stem | Alloy, 31.8mm, 45mm |
| Grips | Entity MTB, Closed End |
| Headset | 44mm Zero Stack, 8mm Cone |
| Seatpost | Alloy, Two Bolt |
| Saddle | Sport MTB |
| Pedals | Nylon Platform |
Geometry:
| S | M | L | |
|---|---|---|---|
| STACK | 585 | 589 | 594 |
| REACH | 432 | 451 | 473 |
| HEADTUBE ANGLE | 67 | 67 | 67 |
| HEADTUBE LENGTH | 115 | 120 | 125 |
| SEATTUBE ANGLE | 74 | 74 | 74 |
| SEATTUBE LENGTH | 406 | 450 | 490 |
| TOPTUBE EFFECTIVE | 600 | 620 | 643 |
| BB HEIGHT | |||
| BB DROP | 40 | 40 | 40 |
| CHAINSTAY | 435 | 435 | 435 |
| WHEELBASE | 1142 | 1163 | 1187 |
| STANDOVER HEIGHT | |||
| FORK OFFSET | 42 | 42 | 42 |
| SEATPOST DIAMETER | 30.9 | 30.9 | 30.9 |
| HANDLEBAR WIDTH | 760 | 760 | 760 |
| STEM LENGTH | 45 | 45 | 45 |
| CRANK LENGTH |
*All lengths in millimeters
