+3532840609The Croix de Fer - now more capable and adaptable than ever before!
The ultimate steel Croix.
Our all-new full-build Reynolds 853 Croix de Fer 50 aims to hit every mark.
Probably the most popular and widely used of all of Reynolds' performance-orientated steel offerings; 853 hits that sweet spot of performance, weight and cost. Accept no imitations - every tube is 853 creating that unmistakable ride quality!
It's matched to our full carbon CGR1 fork that saves around 900-grams over the steel variant, keeping weight low, handling keen and features bottle/Anything Cage mounting points.
We've continued that trend throughout the build, using quality components that are proven and will stand the test of time.
Shimano's GRX groupset has become a go-to for gravel bikes, providing dependable shifting, myriad gearing options and longevity at a variety of performance levels.
We've chosen their RX600 double chainset with 46/30T chainrings, paired to an 11-34T cassette, which keeps the Croix competitive on road and off
The shifters, hydraulic brake callipers and derailleurs all come from the top-tier RX-810 lineup, saving a little weight and delivering increased shifting and braking performance.
At the rear of the bike, there's the ability to run a 45mm tyre on the provided 700c rims, while at the front you can use up to a 40mm tyre. If you'd prefer to run a 650B wheelset, it's 44mm and 40mm.
Thru-axles front and rear, tubeless ready rims and tyres, flat mount disc brakes, a third bottle mount and rack and guard mounts complete the package.
Specifications:
10 | 20 | 30 | 40 | 50 | |
---|---|---|---|---|---|
Frame | Genesis Mjolnir seamless double-butted chromoly | Reynolds 725 Heat-Treated chromoly | Reynolds 725 Heat-Treated chromoly | Reynolds 725 Heat-Treated chromoly | Reynolds 853 Seamless Air-Hardened Heat Treated steel |
Fork | Chromoly disc fork with anything cage mounts | Chromoly disc fork with anything cage mounts | Chromoly disc fork with anything cage mounts | Chromoly disc fork with anything cage mounts | Genesis CGR1 carbon fork |
Headset | PT-1606 EC34 Upper/EC34 Lower | PT-1770 EC34 Upper/ EC34 Lower | PT-1770 EC34 Upper/ EC34 Lower | PT-1770 EC34 Upper/ EC34 Lower | PT-1770 EC34 Upper/ EC34 Lower |
Stem | Genesis Alloy, 31.8mm, -6 deg, 100mm | Genesis Alloy, 31.8mm, -6 deg, 100mm | Genesis Alloy, 31.8mm, -6 deg, 100mm | Genesis Alloy, 31.8mm, -6 deg, 100mm | Genesis Alloy, 31.8mm, -6 deg, 100mm |
Handlebars | Genesis Alloy, 16 deg flare, XS = 400MM, SM/MED = 420MM, L-XL = 440MM | Genesis Alloy, 16 deg flare, XS = 400MM, SM/MED = 420MM, L-XL = 440MM | Genesis Alloy, 16 deg flare, XS = 400MM, SM/MED = 420MM, L-XL = 440MM | Genesis Alloy, 16 deg flare, XS = 400MM, SM/MED = 420MM, L-XL = 440MM | Genesis Alloy, 16 deg flare, XS = 400MM, SM/MED = 420MM, L-XL = 440MM |
Rims | Jalco XCD21 | Jalco XCD21 | Jalco XCD21, 32H | WTB ST i23 TCS 2.0, 32H | WTB ST Light i23 TCS 2.0 |
Spokes | Steel 14g | steel 14g | Steel 14g | Steel 14g | Steel 14g |
Hubs | KT-K68, 6 Bolt, 32h | KT-K08, 6 bolt, 32h | Formula F - RX-812, R - RX-300 | Formula Front - CL-712 / Rear - RXC-142S | Formula Front - CL-712 / Rear - RXC-142S |
Tyres | |||||
Shifter | Shimano Sora ST-R3000 9spd | Shimano Tiagra ST-4700 10spd | Shimano 105 ST-R7000 11spd | Shimano GRX ST-RX600 11spd | Shimano GRX ST-R810 11spd |
Rear Derailleur | Shimano Sora R3000 9spd GS cage | Shimano GRX RD-RX400 10spd | Shimano GRX RD-RX810 Medium cage | Shimano GRX RD-RX810 Medium cage | Shimano GRX RD-RX810 Medium cage |
Front Derailleur | Shimano Sora R3000 band on | Shimano GRX FD-RX400 | Shimano GRX FD-RX810 | Shimano GRX FD-RX810 | Shimano GRX FD-RX810 |
Crankset | Genesis TAF37 46/30T, XS = 165mm, S/M = 170mm, L/XL = 175mm | Shimano GRX FC-RX600 46/30T XS = 165mm, S/M = 170mm, L/XL = 175mm | Shimano GRX FC-RX600 46/30T XS/S = 170MM, M/L= 172.5mm, XL= 175mm | Shimano GRX FC-RX600 46/30T XS/S = 170MM, M/L= 172.5mm, XL= 175mm | Shimano GRX FC-RX600 46/30T XS/S = 170MM, M/L= 172.5mm, XL= 175mm |
Cassette | Shimano CS-HG400-9 11/34T 9spd | Shimano CS-HG500-10 11/34T 10spd | Shimano CS-HG70011 11/34T 11spd | Shimano CS-HG70011 11/34T 11spd | Shimano CS-HG800-11 11/34T 11spd |
Chain | KMC X9 | KMC X10 | KMX X11 | KMX X11 | KMX X11 |
Bottom Bracket | Shimano BB-RS500 | ||||
Brakes | TRP SPYRE-C mechanical disc | TRP SPYRE-C mechanical disc | TRP SPYRE-C mechanical disc | Shimano GRX BR-RX400 | Shimano GRX BR-RX810 |
Brake Levers | Shimano Sora ST-R3000 9spd | Shimano Tiagra ST-4700 10spd | Shimano 105 ST-R7000 11spd | Shimano GRX ST-RX600 11spd | Shimano GRX ST-R810 11spd |
Seatpost | Genesis Alloy 27.2 x 350mm | Genesis Alloy 27.2 x 350mm | Genesis Alloy 27.2 x 350mm | Genesis Alloy 27.2 x 350mm | Genesis Alloy 27.2 x 350mm |
Saddle | Genesis | Genesis | Genesis | Genesis | Genesis |
Pedals | NW-91K with cage | NW-91K with cage | NW-91K with cage | NW-91K with cage | NW-91K with cage |
Geometry
XS |
S |
M |
L |
XL |
|
---|---|---|---|---|---|
Reach | 365 | 375 | 385 | 395 | 405 |
Stack | 553 | 572 | 593 | 612 | 633 |
Effective TT Length | 524 | 544 | 561 | 582 | 605 |
Seat Tube Length | 470 | 500 | 530 | 550 | 580 |
Effective St Angle | 74 | 73.5 | 73.5 | 73 | 72.5 |
Head Tube Length | 115 | 135 | 155 | 175 | 195 |
Head Tube Angle | 71 | 71 | 71.5 | 71.5 | 72 |
Wheelbase | 1007 | 1023 | 1035 | 1052 | 1063 |
BB Drop | 73 | 73 | 73 | 73 | 73 |
Stand Over Height | 761 | 784 | 808 | 826 | 850 |
Fork Offset | 50 | 50 | 50 | 50 |
50 |
